Acnovo GX10 GNSS Receiver

Product Description

Acnovo GX10 GNSS Receiver

CV. Karya Mandiri Techindo has a wide range of Acnovo products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..

Equipped with the most advanced GNSS board, ACNOVO GX10 receiver can track most signals from all types of satellites, including B1, B2 signals from Beidou, and can also be positioned using Beidou alone.
Using the built-in electronic level, you can correct the shooting results and perform inspections without leveling. The built-in tilt sensor allows the receiver to shoot without centering, improving inspection efficiency. The tilt angle can reach 30 degrees.

ACNOVO GX10 is able to transmit corrections from the base station to other explorers via the built-in radio, greatly improving the device’s utility and field flexibility. Embedded Linux operating system + ACNOVO intelligent cloud platform.

• Trimble BD970 220-channel GNSS board;
• Tracking GPS/GLONASS/COMPASS;
• GSM/UHF modem;
• Automatic tilt angle compensation and built-in electronic level;
• Shared Linux OS, cloud platform;
• Correction relay function from the base station

The new integrated GNSS receiver includes most of the latest technologies and features. The open platform at the heart of the device allows you to create and download operating applications directly to the receiver. Automatic tilt angle compensation and built-in electronic level increase the speed and accuracy of work. The multi-system dual-frequency GNSS receiver Acnovo GX10 is made in a monoblock case and can be used in geodetic work as a rover or base receiver.

The basis of the receiver is the Trimble BD970 220-channel GNSS board, which allows you to track satellites of existing systems, including Beidou. The IP68-rated housing ensures reliable operation of the receiver even after immersion in water to a depth of 1 m, and the structural strength is maintained even after falling from a height of 2 m on a concrete base. Raw data for post-processing is recorded into 4 GB of internal memory; if necessary, you can use an SD card up to 32 GB.
Setup and monitoring of the device status in the field is carried out using two control buttons, six status indicators and an LCD display. The built-in tilt sensor allows you to shoot with a mast tilt of up to 30 degrees.

The ACNOVO GX10 has the function of relaying corrections from the base station to the rover via the built-in radio modem, which expands the flexibility of field work and the possibilities of using the receiver. Linux OS together with the ACNOVO cloud platform provide ample opportunities for configuring the receiver to solve various problems.

Specifications Acnovo GX10 GNSS Receiver

• Tracking GPS/GLONASS/COMPAS;
• VHF modem frequency 403-473 MHz;
• GSM-GPRS 3.5G, Bluetooth, Wi-Fi 2.4GHz;
• Memory 4 GB, support MicroSD up to 32 GB;
• Tilt sensor;
• Web interface;
• Removable battery 3400 mAh, static operation up to 30 hours;
• Protection degree IP68;
• Weight: 1.32 kg with battery, dimensions 14cm x 14.4cm;
• Operating temperature -45°С…+65°С.

Packages:

• GX10 GSM/UHF receiver;
• External GSM/GPRS antenna;
• External UHF antenna 430-450 MHz;
• Li-Ion battery 3400mAh – 2 pcs.
• Charger;
• 3-meter tape measure;
• Disk with user manual and software in Russian;
• Transport case.

Additional options:

• External VHF radio modem 35W with external antenna.
