Aditeg OS-310 Analog Oscilloscope 10 Mhz

Karya Mandiri Techindo has a wide range of Aditeg products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..

Specifications Aditeg OS-310 Analog Oscilloscope 10 Mhz


Oscilloscope Type Analog
Frequency			10 Mhz
Channel Number			1
Vertical Deflection Up Time			D35ns, Sensitivity: 5mV / div … 5V / div 3%, Input Impedance: 1M 3%, 30Pf 5PF,
Max Input voltage			400V (peak – peak), Bandwidth (- 3dB): DC 0 … 10Mhz, 10Mhz Ac … 10Hz, Adjustment
Coefficient			E2, 5: 1
Basic Horizontal deflection Time			0, 1 S / Div … 0, 1S / div 3%,
coefficient adjustment			E2, 5: 1
Xy 10Hz mode … 500Khz, Sensitivity			0, 5V / Div, Bandwidth (- 3dB)
Trigger Sensitivity			1Div (Int), 0, 3V (Ext), Ext Input Impedance: 1M 3%, 30Pf 5PF, Max. Ext Input Voltage: 400V (peak – peak), Trigger Mode: Norm, Auto, Tv, Trigger Source: Int, Line, Ext
Voltage Calibration			0, 5V 2%, Source: 1kHz 2%
Cathode Ray Tube Accelerate Voltage			120V, Size: 60X48mm (8X10 Div)
Power Consumption			25W
Dimensions			190 X 130 X 270mm
Weight			3 kg
Power Supply			230Vac 50/60 Hz
In accordance with Norma En61010 600V Cat Ii

Standard Accessories:

Aditeg OS-310
User manual
Probe Oscilloscope 1 Pc
Power cable

Aditeg OS-310 – Datasheet
