Product Description
Amprobe TACH-10 Contact and Non-Contact Tachometer
Karya Mandiri Techindo has a wide range of Amprobe products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
Universal, economical tachometer measuring rotational or surface speed either in contact or non-contact way. Widely used to measure rotational speed of motors, conveyer belts and other moving or rotating systems.
Features Amprobe TACH-10 Contact and Non-Contact Tachometer
- Measures rotational and surface speed
- User selectable units for contact measurement: RPM, m/min, ft/min, yd/min
- Non-contact measurement in RPM
- Digital display
- Auto power off function
- Easy to select units and mode functions
Specifications Amprobe TACH-10 Contact and Non-Contact Tachometer
| Feature | TACH-10 |
| Rotation (non-contact) | 10.0 rpm → 99999 rpm |
| Rotation (contact) | 10.0 rpm → 19999 rpm |
| Surface speed (contact) | 1.0000 m/min → 9999.9 m/min 3.0000 ft/min → 30,000 ft/min |
| Specifications | |
| LCD size | 15(H)x33(W)mm (0.6 x 1.3 IN) |
| Battery | 9V battery |
| Power consumption | 5uA(Idle), 18mA(measurement) |
| Time base | 4.0Mhz Quartz Crystal |
| Sampling time | 1 second (>60RPM), >1 second (10~60RPM) |
| Measure distance | 5~30cm / 2~13 IN (non-contact) |
| Included accessories | Meter, 9V battery, cone funnel contact tips, reflective tape, users manual |
For complete specs please download the product datasheet under the “Resources” tab.
What’s Included
| Description | |
Included Accessories: Batteries (installed), users manual, reflective tape |
Amprobe TACH-10 – Manual
