Description
Benetech GM8903 Hot Wire Anemometer
Karya Mandiri Techindo has a wide range of Benetech products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
The slim sensor of the thermal anemometer is suitable for measurement in narrow spaces, and the handle can be elongated for suitable measurement occasions.
Features Benetech GM8903 Hot Wire Anemometer
- Measurement of wind velocity, temperature and flow
- Unit conversion of wind velocity, temperature and flow
- Measurement of maximum and minimum wind velocity
- Measurement of 2/3 Vmax and average wind flow
- Data holding, storing and deleting function
- Low battery indicating function
- It turns off automatically within 10 minutes if there is no further operation. it will not turn off automatically if there is powered by USB source
- Memory of 350 records
- Backlight
- Connecting to PC with USB cable
- Audio key pressing alert
- Large LCD display
Specifications Benetech GM8903 Hot Wire Anemometer
| Power supply | AAA 1.5V Alkaline battery *4 | |||
| Low battery indicating | 4V±0.2V | |||
| Stand by current | 0uA | |||
| Operating Current | ≤60mA | |||
| Battery use life | 20H (Continuous Use ) | |||
| Dimensions | – Meter :77x36x164mm – Probe 30.5×30.5x305MM – 30.5×30.5x1000MM(Elongated) | |||
| Net Weight | 330G (Not Included Battery ) | |||
| Wind Velocity Range | ||||
| Unit | Wind Velocity | Resolution | Lowest Point of start value | Accouracy |
| m/s | 0.0-30.0 | 0.001 | 0.3 | ±3%±0.1 |
| Ft/min | 0.0-5860 | 0.01/0.1/1 | 60 | ±3%±20 |
| Knots | 0.0-55.0 | 0.01/0.01 | 0.6 | ±3%±0.2 |
| Km/h | 0.0-90.0 | 0.001 | 1.0 | ±3%±0.4 |
| Mph | 0.0-65 | 0.001/0.01 | 0.7 | ±3%±0.2 |
| Wind flow range | ||||
| CMM | 0-999900m³ /min | |||
| CFM | 0-999900 ft³ /min | |||
| Unit | Range | Resolution | Area | |
| CFM(FT³ /MIN) | 0-999900 | 0.001-100 | 0.001-9999 | |
| CMM(M³ /MIN) | 0-999900 | 0.001-100 | 0.001-9999 | |
| Air Temperature Range | ||||
| Wind Temperature | ||||
| Unit | Scale | Resolution | Accuracy | |
| ℃ | 0.0-45.0 | 0.1 | ±1.0℃ | |
| ℉ | 32.0-113.0 | 0.1 | ±1.8℉ | |
Include:
- handle*1
- Color box*1
- Cloth bag*1
- Charging Cable*1
- Host*1
- Instructions*1
- CD*1
- 1.5V AAA battery*4
Benetech GM8903 – Manual
