Product Description
BSIDE S11 Smart Multimeter
Karya Mandiri Techindo has a wide range of BSIDE products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
Features BSIDE S11 Smart Multimeter
- Multifunctional Multimeter with Wide Test : the digital multimeter can measure AC/ voltage, resistance, capacitance, frequency, diode, continuity, NCV live line.
- Functions: measuring diodes within 3V. when the resistance is less than 50O, the will sound up when measuring resistance. The sounds when live voltage signal recognized
- Rechargeable Li-ion : built-in 800mAh rechargeable li-ion , convenient to use and recharged.
- High Display: the 3.5-inch large EBTN LCD greatly enhance the reading experience, the value is very easy to read even under the sunlight or poor light condition.
- Reliable & Practical: NCV measurement, auto ranging 9999 counts multimeter with DATA hold function.
- Safety Assurance: with full measuring overload , double insulation , .II 600V and .III 300V safety level.
- Digital Pocket Size Handheld Multimeter: compact portable size designed and with a sleeve and a storage pouch for protecting against shocks, friction and bumps.
Specifications BSIDE S11 Smart Multimeter
| Color | Black / Red (Optional) | ||
| Voltage | 0.8~620V | ||
| AC Voltage | 2.2~620V | ||
| Resistance | 1O~999.9O, 1kO~60MO | ||
| Capacitance | 1nF~999.9nF, 1µF~99.99mF | ||
| Frequency | 1Hz~1kHz(ACV 2~10V), 1Hz~60kHz(ACV10~620V) | ||
| Duty Ratio | 0.1%~99.9% (ACV2~620V) | ||
| Material | ABS | ||
| Safety Level | II 600V, .III 300V | ||
| Display | Color LCD | ||
| Max. Display | 9999 digits | ||
| Sampling | About 0.4 seconds | ||
| Auto -off | 5 minutes | ||
| Operate Environment | 0~40?, 0~80%RH | ||
| Storage Environment | -10~60?, 0~70%RH | ||
| Operate Altitude | 2000m | ||
| Item Size | 143.4 * 70.9 * 15.7mm / 5.65 * 2.79 * 0.62in | ||
| Item Weight | 119g / 4.20oz | ||
| Package Weight | 320g / 11.29oz | ||
| Package Size | 16.9 * 9.5 * 4.4cm / 6.65 * 3.74 * 1.73in |
Packing List
- 1 * Multimeter
- 1 * Pair of Test Pen
- 1 * USB Cable
- 1 * Protective Sleeve
- 1 * Storage Pouch
- 1 * Manual
Klik Video dibawan ini :
| BSIDE S11 Smart Multimeter | BSIDE S11 Smart Multimeter |
| BSIDE S11 Smart Multimeter |
Produk asli Kami distributor langsung BSIDE . Harga murah dan berkualitas bergaransi tentunya. dapat di kirim ke seluruh wilaya indonesia.
Dalam pengiriman produk yang pelanggan beli, sebelumnya sudah kami cek untuk memastikan produk dalam keadaan baik dan siap kirim.
