Description
CHNSpec CS-10 Colorimeter
Karya Mandiri Techindo has a wide range of CHNSpec products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
Colorimeter is widely used in different industries such as plastic, printing, paint, textile,dyeing,etc. It measures the sample color values of L*a*b*, L*c*h*, color difference ΔE and ΔLab according to CIE color space.
- Introduction
Device sensor exports Japan and processing chip is from USA, which guarantee the optical signal transfer accuracy and electrical signal stability. Display accuracy reaches 0.01, repeated test accuracy △E deviation value is below 0.10. - Multiple color space display color values : L*a*b,L*c*h,Yxy
Being the most commonly used testing device, our colorimeter with built-in color display indicators transformation program, which makes our device could be used for color testing in many different industries. And it do not need convert the measurement data by manual which greatly improve the work efficiency. - Ergonomic Design
Instrument designs according to human palm so we could test data for long time with it. Superior leather design increases the friction in case of fingers sliding. - Free Color Management Software
Real-time display of pass or fail, generate testing report, save the color values, suitable for enterprise to evaluate color and management the color value. - Establish L*a*b* by manually
The standard samples can be manually set to meet the color difference test if there is no sample in hand. - Large store memory
The device could store 100 standard sample groups and every sample group could store 100 sample data. - Average Measurement Values
Test different points on sample and get the average value. It is widely used for color control whose color is not uniform. - Technical Support
One Year Guarantee Time.
Colorimeter CS-10 Application
Specifications CHNSpec CS-10 Colorimeter
| Type | CS-10 |
| Illumination system | 8/d（8°/diffused illumination） |
| SCI | |
| Testing Port Diameter | 8mm |
| Measuring conditions | CIE 10° standard observer; CIE D65 light source |
| Display | Chromaticity Value: L*a*b,L*c*h, △E*ab,XYZ,Yxy, Relative RGB,color difference △E*ab, △E*ch |
| Measuring range | L*:1-100 |
| Repeatability | Standard deviation within △E*ab*, below 0.1(testing condition: measure the white calibration board for average) |
| Storage | 10 sets of standard samples; up to 100 under each standard sample |
| Measuring time | About 0.5 seconds |
| Measuring light source | LED |
| languages | Chinese, English |
| Power | Four AA1.5V Alkaline battery or nickel-metal hydride batterys; Exclusive DC5V adapter |
| port | USB2.0 printer |
| weight | 550g |
| Size | 77×86×210mm |
CHNSpec CS-10 – Manual
