Description
Extech 45170 4-in-1 Environmental Meter
Karya Mandiri Techindo has a wide range of Extech products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
This 4-in-1 meter measures Humidity, Temperature, Air Velocity and Light. The dual LCD simultaneously displays Temperature and Air Velocity or Relative Humidity. High Temperature air or surface measurements can be made using the built-in Type K input. Comes complete with built-in Humidity sensor, Light sensor and Vane wheel, wrist strap, and 9-Volt battery.
Features Extech 45170 4-in-1 Environmental Meter
- Ergonomic pocket size housing with large dual LCD simultaneous display of Temperature and Air Velocity or Relative Humidity
- Characters on display reverse direction depending on Hygro-Thermo-Anemometer or Light Mode
- Data Hold to freeze the displayed value
- Records Min/Max readings
- Built-in low friction vane wheel improves accuracy of air velocity in ft/min, MPH, m/s, km/h, and Knots
- Built-in precision thin-film capacitance humidity sensor for fast response
- Built in thermistor for ambient temperature measurements
- High temperature measurements using Type K thermocouple
- Utilizes precision photo diode and color correction filter
- Cosine and color corrected light measurements
- Auto power off, Low Battery and overrange indication
- Complete with built-in Humidity sensor, Light sensor and Vane wheel, wrist strap, and 9V battery
Specifications Extech 45170 4-in-1 Environmental Meter
| Measurements | Range | Resolution | Basic Accuracy |
|---|---|---|---|
| Air Velocity | |||
| ft/min | 80 to 5910 ft/min | 10ft/min | ±3% FS |
| m/s | 0.4 to 30m/s | 0.1m/s | ±3% FS |
| km/h | 1.4 to 108km/h | 0.1km/h | ±3% FS |
| MPH | 0.9 to 67MPH | 0.1MPH | ±3% FS |
| knots | 0.8 to 58.3 knots | 0.1knots | ±3% FS |
| Light | |||
| Foot Candles (Fc) | 0 to 1860Fc | 0.1Fc | ±(5% rdg + 8 digits) |
| Lux | 0 to 20,000Lux | 1Lux | ±(5% rdg + 8 digits) |
| Relative Humidity | 10 to 95%RH | 0.1%RH | ±4%RH of rdg |
| Temperature (Thermistor) | 32 to 122°F (0 to 50°C) | 0.1° | ±2.5°F (1.2°C) |
| Temperature (Type K) | -148°F to 2372°F (-100°C to 1300°C) | 0.1° | ±(1%+2°F)/(1%+1°C) of rdg |
| Dimensions | Meter: 6.1 x 2.4 x 1.3″ (156 x 60 x 33mm); Vane: 1.2″ (31mm) | ||
| Weight | 5oz (160g) | ||
Extech 45170 – Datasheet
