Extech MG500 Digital High Voltage Insulation Tester
Karya Mandiri Techindo has a wide range of Extech products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
The MG500 is a digital high voltage insulation tester that tests voltage up to 10kV and measures insulation resistance to 500GOhm. The MG500 has a CAT III 300 Volt safety rating. This product is complete with a year warranty, built-in heavy duty carrying case with cover, test leads, alligator clips, and 8 x C batteries.
Features Extech MG500 Digital High Voltage Insulation Tester
- High test voltages up to 10kV with Insulation Resistance to 500GOhm
- Polarization Index (PI) measurement
- Dielectric Absorption Ratio (DAR) measurement
- EnerSave™ limits test duration to 10 seconds to save energy
- Complete with built-in heavy duty carrying case with cover, test leads, alligator clips, and 8 x C batteries
Specifications Extech MG500 Digital High Voltage Insulation Tester
| Specifications | Range |
|---|---|
| Insulation Resistance | 800kΩ to 500GΩ ( Autoranging ) |
| Resolution | 1kΩ |
| Basic Accuracy | ±5% |
| Test Voltages | 500VDC to 10kVDC (adjustable in 500V steps) |
| Preset Buttons | 1kV, 2.5kV, 5kV, 10kV |
| Polarization Index | Yes |
| Dielectric Absorption Ratio | Yes |
| Voltage Output Warning | Yes |
| Automatic Discharge | Yes |
| Dimensions | 13×10.2×6.3” (330x260x160mm) |
| Weight | 7.9lbs (3.6kg) |
Extech MG500 – Datasheet
