Product Description
Feeltech FY6600-60M Signal Generator
Karya Mandiri Techindo has a wide range of Feeltech products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
FeelTech FY6600-60M 60MHZ Digital Control, Dual Channel, DDS Function, Signal Generator, EU Arbitrary Frequency Meter
- Adopt DDS (Direct Digital Synthesizer) technology and provide stable, accurate, pure and weak distortion signals.
- 4″ TFT color LCD screen with 320*240 resolution, simultaneously display CH1 and CH2 settings and graphics.
- Use a high speed 14 bit N / A conversion chip (the output quantification error of 5 Vpp is less than 1 mV), a sample rate of 250 Mpa / s and a vertical resolution of 14 bits.
- You can generate up to 97 groups of arbitrary functions/signals: 33 groups of preset signals and 64 groups of user-defined signals.
Frequency Parameters
| Sine Wave Range | 0Hz~60MHz | ||
| Triangle Wave | 0Hz~10MHz | ||
| Ramp Pulse Wave | 0Hz~10MHz | ||
| Arbitrary Waveform | 0Hz~10MHz | ||
| TTL/COMS | 0Hz~20MHz | ||
| Min. Pulse Width | 20ns(Pulse wave minimum width of all models can reach 20ns) | ||
| Min. Resolution | 1 μHz | ||
| Frequency Accuracy | +/-20ppm | ||
| Frequency stability | +/-1ppm/3 hours |
Waveform Parameters
| Waveform Types | Sine, Square (Duty Cycle adjustable), Pulse (Pulse width and cycle time can be set accurately), Triangle/Ramp, Sawtooth Wave, CMOS, Four channels TTL, DC, Half wave, Full wave, Positive Step, Inverse Step, Positive Exponent, Inverse Exponent, Lorenz form other sets Pulse, Multitone, Noise, ECG, Trapezoider-Pulse, Nausse | ||
| Waveform Length | 8192 points * 14 bits | ||
| Sampling Rate | 250MSa/s | ||
| Vertical resolution | 14 bits | ||
| Sine: Harmonic Suppression | ≥50dBc(<1MHz); ≥45dBc(1MHz~20MHz) | ||
| Total Harmonic Distortion | <0.5% (20Hz~20kHz,0dBm) | ||
| Square: Rise/Fall Time | ≤7ns(VPP<5V) | ||
| Overshoot | ≤5% | ||
| Duty Cycle | 0.01%~99.99% (Resolution 0.01%) | ||
| Sawtooth Wave | Linearity >99% (0.01Hz~10kHz) |
Output Parameters
| Amplitude(VPP) | Frequency≤10MHz 10MHz20MHz 1mVpp~20Vpp 1mVpp~10Vpp 1mVpp~5Vpp |
||
| Resolution | 1mV | ||
| Amplitude stability | +/-0.5%/5 hours | ||
| Flatness range | +/-2.5% (<10MHz); +/-5% (>10MHz) | ||
| Waveform Output | |||
| Impedance | 50Ω +/-10% (Typical) | ||
| Protection | All channels can work within 60s under load short-circuit condition | ||
| DC Offset | |||
| Offset Range | Frequency≤20MHz: +/-10V; Frequency>20MHz: +/-2.5V |
||
| Offset Resolution | 1mV | ||
| Phase Parameters | |||
| Phase range | 0~359.99° | ||
| Phase Resolution | 0.01° | ||
Package includes:
- 1 x DDS Signal Generator.
- 1 x CD
- 1 x power cable.
- 1 x USB Data Cable.
- 1 x BNC-BNC cable.
- 2 x BNC-Clip Cable.
