Description
Hanna HI5522 Laboratory Research Grade Benchtop pH/mV/ISE and EC/TDS/Salinity/Resistivity Meter
Karya Mandiri Techindo has a wide range of Hanna Instruments products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
Get reliable measurements with our most advanced benchtop pH meter.
This benchtop pH meter is the essential tool for any lab. Rich in features and completely customizable to user specific requirements, the HI5522 delivers precision and performance for the most demanding user.
- Compact design to fit onto any lab benchtop
- Two channels for simultaneous measurements to maximize your testing time
- Great for laboratory and professional use
Specifications Hanna HI5522 Laboratory Research Grade Benchtop
| Specification Name | Detail |
|---|---|
| SKU | HI5522-01 |
| pH Range | pH: -2.000 to 20.000; mV: ±2000 |
| pH Resolution | pH: 0.1, 0.01, 0.001; mV: 0.1 |
| pH Accuracy (@25°C/77°F) | ±0.1 pH, ±0.01 pH, ±0.002 pH ±1 LSD; ±±0.2 mV ±1 LSD |
| pH Calibration | automatic, up to five point calibration, eight standard buffers available (1.68, 3.00, 4.01, 6.86, 7.01, 9.18, 10.01,12.45) and five custom buffers |
| pH Temperature Compensation | automatic or manual from -20.0 to 120.0 °C |
| EC Range | 0.000 to 9.999 μS/cm, 10.00 to 99.99 μS/cm, 100.0 to 999.9 μS/cm, 1.000 to 9.999 mS/cm, 10.00 to 99.99 mS/cm, 100.0 to 1000.0 mS/cm actual EC* |
| EC Resolution | 0.001 μS/cm, 0.01 μS/cm, 0.1 μS/cm, 1 μS/cm, 0.001 mS/cm, 0.01 mS/cm, 0.1 mS/cm |
| EC Accuracy | ±1% of reading (±0.01 μS/cm) |
| EC Calibration | automatic standard recognition (0.000 μS/cm, 84.00 μS/cm, 1.413 mS/cm, 5.000 mS/cm, 12.88 mS/cm, 80.00 mS/cm, 111.8 mS/cm) or user standard; single point or multi-point calibration |
| TDS Range | 0.000 to 9.999 ppm, 10.00 to 99.99 ppm, 100.0 to 999.9 ppm, 1.000 to 9.999 ppt, 10.00 to 99.99 ppt, 100.0 to 400.0 ppt actual TDS* (with 1.00 factor) |
| TDS Resolution | 0.001 ppm, 0.01 ppm, 0.1 ppm, 1 ppm, 0.001 ppt, 0.01 ppt, 0.1 ppt |
| TDS Accuracy | ±1% of reading (±0.01 ppm) |
| EC/TDS Temperature Compensation | disabled, linear and non-linear (natural water) |
| Temperature Correction Coefficient | 0.00 to 10.00 %/°C |
| Salinity Range | practical scale: 0.00 to 42.00 psu; natural seawater scale: 0.00 to 80.00 ppt; percent scale: 0.0 to 400.0% |
| Salinity Resolution | 0.01 for practical scale/natural seawater scale; 0.1% for percent scale |
| Salinity Accuracy | ±1% of reading |
| Salinity Calibration | percent scale—one-point (with HI7037 standard) |
| Salinity Temperature Compensation | disabled, linear and non-linear (natural water |
| Temperature Range | -20.0 to 120.0 ˚C**; -4.0 to 248.0 ˚F**; 253.15 to 393.15 K** |
| Temperature Resolution | 0.1 °C, 0.1 °F, 0.1 K |
| Temperature Accuracy | ±0.2 °C; ±0.4 °F; ±0.2 K (without probe) |
| ISE Range | 1 x 10⁻⁶ to 9.99 x 10¹⁰ concentration |
| ISE Resolution | 1; 0.1; 0.01; 0.001 concentration |
| ISE Accuracy @ 25 °C/77 °F | ±0.5% (monovalent ions); ±1% (divalent ions) |
| ISE Calibration Points | automatic, up to five point calibration, five fixed standard solutions available (0.1, 1, 10, 100, 1000 choice of concentration) and five user defined units |
| pH Electrode | HI1131B glass body pH electrode with BNC connector and 1 m (3.3’) cable (included); |
| EC/TDS Probe | HI76312 platinum, four-ring EC/TDS probe with and 1 m (3.3’) cable (included) |
| Temperature Probe | HI7662-T stainless steel temperature probe with 1 m (3.3’) cable (included) |
| Power Supply | 12 VDC adapter (included) |
| Environment | 0 to 50°C (32 to 122°F; 273 to 323 K), RH max 95% non-condensing |
| Dimensions | 160 x 231 x 94 mm (6.3 x 9.1 x 3.7”) |
| Weight | 1.2 kg (2.64 lbs.) |
| Ordering Information | HI5522 is supplied with HI1131 pH electrode, HI7662-T temperature probe, HI76312 conductivity probe, HI76404W electrode holder, HI70004 pH 4.01 buffer solution sachet, HI70007 pH 7.01 buffer solution sachet, HI700601 electrode cleaning solution sachet (2), HI7082 3.5M KCl electrolyte solution (30 mL), 12 VDC power adapter and instructions. |
| Method | USP <645> Compliant |
| Special Notes | *Uncompensated conductivity (or TDS) is the conductivity (or TDS) value without temperature compensation. **Reduced to actual probe limits |
Hanna HI5522 – Manual
