Horiba LAQUAtwin EC-11 Conductivity Meter

The only pocket meter that directly measures conductivity and total dissolved solids (TDS) in 0.12ml sample. No need for a beaker to calibrate your meter or measure a sample. Just place few drops of the standard or sample onto the sensor. This procedure saves you time and prevents wasting your precious sample.

Features Horiba LAQUAtwin EC-11 Conductivity Meter

* Minimum sample volume: 0.12ml
* Up to 3 calibration points
* Conductivity, TDS, and temperature display
* Auto range
* Auto calibration
* Auto standard recognition: 1413µS/cm, 12.88mS/cm, 111.8mS/cm
* Auto temperature compensation: 2%/ºC fixed
* Temperature calibration: 5 to 40.0 ºC
* 4 Total dissolved solids curves: TDS Factor 0.4 to 1.0, EN 27888, 442, NaCl
* Auto stable / auto hold measurement
* Auto power off: 30 mins.
* Low battery indicator
* IP67 Rating dust & waterproof
* Replaceable sensor
* 400 Hours battery life: continuous use without backlight
* Materials: ABS epoxy body & titanium coated with platinum black sensor
* Display: custom (monochrome) LCD with backlight
* Operating conditions: 5 to 40°C, 85% or less relative humidity
* Warranty: 2 years – meter, 6 months – sensor
* Packed in handy carrying case
* Supplied with 1413µS/cm & 12.88mS/cm conductivity standards (14ml each), conditioning solution (4ml), 2 x CR2032 batteries, dropper, instruction and quick manuals

Specifications Horiba LAQUAtwin EC-11 Conductivity Meter

Model EC-11 EC-22 EC-33
Measurement Principle  2 Electrode Bipolar AC
Minimum Sample Volume   0.12ml
Conductivity Range & Resolution
0 to 199 µS/cm: 1µS/cm

200 to 1999 µS/cm: 1µS/cm

2.00 to 19.99 mS/cm: 0.01 mS/cm

20.00 to 199.9 mS/cm: 0.1 mS/cm

   •



   •

   •

TDS Range & Resolution
0.0 to 99.9 ppm: 0.1 ppm

100 to 999 ppm: 1 ppm

1000 to 9990 ppm: 10 ppm

   •

TDS Curves

TDS Factor (0.4 – 1.0), EN 27888, 442, NaCl

   •
Conductivity Calibration Points
Up to 2

Up to 3

   •







Accuracy
±2% full scale (for each range)

±2% full scale (0 to 19.99 mS/cm)

±5% full scale (20.0 to 199.9 mS/cm)

   •









Temperature Display 0 to 50.0 °C    •    •
Temperature Calibration 5 to 40.0 ºC    •    •
Display Custom (monochrome) LCD with backlight
Operating Temperature 5 to 40°C
Operating Humidity 85% or less relative humidity (no condensation)
Power CR2032 batteries (2)
Battery Life Approx. 400 hours in continuous use (without backlight)
Dimensions 164 × 29 × 20mm (excluding projections)
Mass Approx. 50 g (including sensor and batteries)
Functions
  • Auto Range
  • Auto Calibration
  • Auto Standard Recognition
  • Auto Temperature Compensation (2%/°C fixed)
  • Temperature Calibration (only for EC-22 & EC-33)
  • Auto Stable / Auto Hold Measurement
  • Auto Power Off (30mins)
  • Switchable Backlight
  • Low Battery Indicator
  • IP67 Dust / Waterproof
  • Replaceable Sensor



Horiba LAQUAtwin EC-11 Conductivity Meter Manual
