Mastech MS6818 Advanced Wire Tracker
Karya Mandiri Techindo has a wide range of Mastech products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
The MASTECH MS6818 is a professional-grade cable tracker designed for identifying and tracking cables or wires within a group and diagnosing open or short circuits. With its robust construction and advanced features, the MS6818 ensures accurate and efficient troubleshooting for both professionals and DIY enthusiasts.
Features Mastech MS6818 Advanced Wire Tracker
- Find the Beaks or Shorts in Cable in the wall or Earth
- Track Cables in the wall or Earth
- Find the Fuse and Safeguard
- Find the Beaks or Shorts in Conduit under the Floor
- Sensitivity of Receiver can be selected
- Auto Ranging,
- Auto Power Off
- Backlight and Worklight
| Current | |
|---|---|
| AC | – |
| DC | – |
| Voltage | |
|---|---|
| AC | 12~400V |
| DC | 12~400V |
Specifications Mastech MS6818 Advanced Wire Tracker
| Technical Parameters of Transmitter | |
| Output Signal | 125kHz |
| External Voltage | DC12~400V AC12~400V(50~60Hz) ±2.5% |
| Fuse | F0.5A 1000V |
| MIN Current | about 31mA |
| MAX Current | about 115mA |
| In Work | 0~40℃, with MAX relative humidity of 80% |
| In Storage | -20~60℃, with MAX relative humidity of 80% |
| Altitude | <2000m> |
| Technical Parameters of Receiver | |
| Depth of Tracking | The Depth of Tracking Depends on the Material and Specific Applications |
| Cable | Single pole application: about 0~2m |
| Locating | Dual pole application: about 0~0.5m |
| Mode | Single loop line: Up to 2.5m |
| MIN Current | about 32mA |
| MAX Current | about 89mA |
| In Work | 0~40℃, with MAX relative humidity of 80% |
| In Storage | -20~60℃, with MAX relative humidity of 80% |
| Altitude | <2000m> |
Transmitter
- Product Size : 190mm x 89mm x 42.5mm / 7.48″ x 3.5″ x 1.67″
- Product Weight : 420g / 0.92lb
- Power Supply : 1x9V 6F22 Battery
Receiver
- Product Size : 241.5mm x 78mm x 38.5mm / 9.5″ x 3″ x 1.5″
- Product Weight : 350g / 0.77lb
- Power Supply : 6×1.5V AAA Battery
- Certificate : CE / ETL / RoHS
- Safety Rating : CAT III 300V
Accessories:
- Test leads
- Test probe
- Alligator clip
- Grounding Rod
- Carry bag
- Battery
- User’s manual
Mastech MS6818 – Datasheet
