Nicety ST2016 Digital Earth Resistance Tester

Description

Nicety ST2016 Digital Earth Resistance Tester

Karya Mandiri Techindo has a wide range of Nicety products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..

The ST2016 Earth Ground Tester is a rugged, easy to use tester for three-pole, two-pole resistance measurements and soil Resistivity.
Earth Ground resistance is measured by installing Earth Ground test electrodes and testing with the ST2016 Earth Ground resistance measurements are used to ensure safe operation and reduce power quality problems. The ST2016 is extremely lightweight making it ideal to test for lightning protection levels and periodic check-ups during routine maintenance.

• Test resolution of 0.003Ω on 200kΩ range
• Advanced Filtering method (based on FFT Fast Fourier Transform) reduces noise interference for obtaining stable measurements.
• Automatic and Manual selection of the Test Current Frequency in four bands (94/105/111/128Hz). In Automatic mode, ST 4106 will select the most suitable Frequency. Several sub-results can be shown on the display: Resistance of the Auxiliary Earth Spikes, Frequency of Test Current, Voltage and Frequency of Interference (noise), Residual Resistance Rk, etc.
• Warning for excessive noise and high Auxiliary Earth Spikes resistance.
• Large Graphic Display with backlight for readings in poorly illuminated areas.
• Up to 999 measurement results can be saved in the memory and recalled on the display.
• The stored results can be transferred to a PC using software and a USB adaptor which are not included.

Features Nicety ST2016 Digital Earth Resistance Tester :

• Earth resistance measurement with 4, 3 and 2wires and six ranges covering measurements from 0.03Ω to 200kΩ.
• Also ideal for large earthing systems by the considerable test current of 20mA (max) yield-ing a high resolution of 0.001Ω on 2Ω range.
• Advanced Filtering method (based on “FFT” Fast Fourier Transform) reduces noise interference for obtaining stable measurements.
• Warnings for excessive noise and high Auxiliary Earth Spikes resistance.

Earth Resistivity Measurement

• The earth resistivity measurement is useful for soil surveys to establish the optimum earth electrode system design and site, to avoid extra cost of re-working electrode installations. It can be also suitable for geological investigations.
• Earth resistivity measurement is automatically calculated after having set the distance between Auxiliary Earth Spikes.

Software

• The stored results can be transferred to a PC via USB adaptor.
• Up to 999 measurement results can be saved in memory.
• Data can be converted to CSV files.

Specification Nicety ST2016 Digital Earth Resistance Tester :
