PCE Instruments PCE-895 Digital Thermometer

CV. Karya Mandiri Techindo has a wide range of PCE Instruments products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..

Dual Laser Infrared Digital Thermometer PCE-895 Cross laser thermometer for non-contact measurement of surface temperatures / Fast response time / Adjustable emissivity / Max-Min function / USB / SD card

The Dual Laser Digital Thermometer PCE-895 is used for fast surface temperature measurement. The two laser points of the dual laser thermometer PCE-895 mark the exact measuring point and thus offer excellent assistance with the temperature measurement. Due to the cross laser function, the two laser spots indicate exactly how large the actual IR spot is. The emissivity of the dual laser thermometer PCE-895 is adjustable in the range of 0.10 … 1.0. Thus, the dual laser thermometer PCE-895 is suitable for almost all surfaces.

The temperature measuring range extends from -35 … 1600°C / -31 … 2912°F. In addition to the IR function, a type K thermocouple can also be connected to the dual laser thermometer. A USB interface and an SD memory card slot complete the functionality of this professional thermometer. The SD card enables data logging of several hours on machines and systems. Using the PC software, the stored temperature profiles can be read out and exported. This makes the Dual Laser Thermometer ideal for long-term temperature measurements.

Features PCE Instruments PCE-895 Digital Thermometer :

Non-contact temperature measurement
60:1 optics
Temperature measurement up to 1600°C / 2912°F
Compact cross laser thermometer
Double laser shows the spot diameter
Adjustable emissivity
Adjustable emissivity
Alarm function

Typical applications of Dual Laser Infrared Thermometer PCE-895 :

Food inspection
Hygiene tests
Road construction
Switch cabinet monitoring
Heating and air conditioning technology
Production monitoring
Temperature measurement on motors

***ATTENTION*** Our temperature sensors are designed for industrial and laboratory surface temperature measurement ONLY. They are not designed or certified for body temperature measurement or for medical use.

Specifications PCE Instruments PCE-895 Digital Thermometer

Infrared
Measuring range	-35 … 1600°C / -31 … 2912°F
Measuring accuracy (at 23 … 25°C ambient temperature)	-35 … 0°C / 0°F: ± 2°C / 3.6°F + 0.05*TObj 0 … 1600°C: ± 2% of rdg. or ± 2°C / 3.6°F
Resolution	1°C / 1.8°F at 1000 …. 1600°C / 1832 … 2912°F

Thermocouple
Measuring range	Type K: -64 … 1400°C / -83 … 2552°F
Measuring accuracy (at 23 … 25°C ambient temperature)	± 1% of rdg. or ± 1°C / 1.8°F
Resolution	0.1°C / 0.18°F at -64 … 999.9°C / -83.2 … 1831.8°F

Emissivity	Adjustable 0.10 … 1.0
Spectral range	8 … 14 µm
Response time	1 s
Optical resolution / measurement spot ratio	60:1
Storage	Internal: 24 memory points External (micro-SD card): max. 8 GB supported
Interface	USB
Display	LCD illuminated
Power supply	2 x 1.5V AA batteries
Operating time	Typical: 14 h Continuous: 10 h
Operating conditions	0 … 50°C / 32 … 122°F
Weight	ca. 400 g / 14.1 oz
Dimensions	203 x 176 x 89 mm / 7.9 x 6.9 x 3.5 in

Delivery Scope:

1 x Digital Thermometer PCE-895
1 x USB Cable
1 x Micro SD Card 8 GB
1 x PC Software
2 x 1.5V AA Batteries
1 x Thermocouple Type K ( 0 … 250°C / 32 … 482°F)
1 x User manual

PCE Instruments PCE-895 – Datasheet
