Product Description
SEW 273 HP Non-Contact Voltage Detector
Karya Mandiri Techindo has a wide range of SEW products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
Features SEW 273 HP Non-Contact Voltage Detector
- 2 ranges for selection :
– LOW 50V~1.5kV
– HIGH 1.5kV~132kV - There is no power consumption in off mode : 0uA
- Nice mechanical slide switch for function selection : HIGH / OFF / LOW
- The power consumption in low voltage detection mode : Less than 20mA
- The power consumption in high voltage detection mode : Less than 20mA
- Bright LED and audible alarm sound when voltage is present
- Lightweight, robust and compact
- Efficient and easy to use
- Users have to use the Hot Stick when test high voltages between 1.5kV~132kV
- SEW provides nice optional accessories of Hot Sticks HS-175 and HS-120 for high voltage detection
- Optional accessories :
– HS-175 Telescopic hot stick (triangle-type)
– HS-120 Hot stick
Specifications SEW 273 HP Non-Contact Voltage Detector
| Operating temperature | 0°C~50°C |
|---|---|
| Dimensions | 245(L) x 80(W) x 37(D)mm |
| Weight (battery included) |
Approx. 175g |
| Power source | 9V(6LF22) x 1 Alkaline battery |
| Safety standards | EN 61326-1 EN 61000-4-2 EN 61000-4-3 |
SEW 273 HP – Datasheet
KARYA MANDIRI TECHINDO adalah Supplier SEW 273 HP Non-Contact Voltage Detector dan juga menjual Brand SEW. Lihat produk kami lainnya di sini JSI, SGI, SMG atau hubungi kami lewat Whatsapp 0821-3010-0456 atau via email [email protected].
