Description

SHIMADZU MOC63U UniBloc Moisture Analyzer

Karya Mandiri Techindo has a wide range of SHIMADZU products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..

Excellent performance for a wide variety of applications in multiple industries

In many fields, a moisture analyzer is a necessary tool for quality control requirements. With the MOC63u, you can easily obtain accurate data. Simply place material on the pan and shut the cover. The MOC63u will start to measure. The MOC63u adapts to various materials and increases your work efficiency.

Features SHIMADZU MOC63U UniBloc Moisture Analyzer

Halogen heater

Long-life and high power halogen heater provides quick and accurate measurement.
The temperature can be changed from 50 degrees to 200 degree Celsius.
You can check sample status from window while measurement.

Large pan size: 95mm dia

MOC63u has large pwn. (95mm diameter)
It can provide quick and accurate measurement to spread sample in thin layer on the pan.

Data management and easy operation

Built-in USB port

The measure results can be transferred by USB cable.
If connect with PC by USB, needs USB driver.
Please download from here.

WindowsDirect

Send balance data to Excel or other Windows applications without installing additional data communication software. By combining standard Auto print functions with typical spreadsheet functions, even difficult applications can be easily automated.

You can create graphs easily with WindowsDirect and Excel.
If you need templates, please download from here. (xls/69KB)
Connection to Windows Vista and Windows7.

Easy operation using a simple keypad

Features easy-to-operate software and keypad layout. In addition, an automatic starting mode saves measurement time, increasing your work efficiency. Operation simply requires ‘putting material on the pan and shutting the cover’. Internal memory can save 10 measurement conditions and 100 results. Various measurement modes provide extra support.

Various measurement modes

Ending modes:
Automatic ending mode

Automatically ends measurement when moisture loss over the previous 30 seconds becomes smaller than specified percentage.

Timed ending mode

Automatically ends measurement when the specified amount of time has elapsed.

Alternative drying modes:
Rapid drying mode

First dries with the highest temperature for the specified period, then shifts to the specified temperature, shortening measurement time.

Slow drying mode

Gently heats samples that might solidify at the surface or samples that reduce under high temperature.

Step drying mode

Allows step-by-step change in drying conditions. This feature is useful when measuring samples that contain a large amount of water.

Specifications SHIMADZU MOC63U UniBloc Moisture Analyzer

Model Name		MOC63u
Capacity	Max. Sample Quantity Min. Sample Quantity	60 g 0.02 g
Minimum Display	Mass Moisture Ratio	0.001 g 0.01 %
Repeatability		0.15 % (2 g), 0.05 % (5 g), 0.02 % (10 g)
Heat Source	Method Power	Halogen (straight tube) Rated at 400 W
Temperature Settings		50 to 200 °C (1 °C interval) (up to 1 hour for settings over 180 °C)
Display		Backlit LCD
Pan Size		Approx. 95 mm dia.
Dimensions		Approx. W202 × D336 × H157 mm
Weight		4.2 kg
Rated Power		430 VA
Ambient Temperature		5 to 40 °C, relative humidity of 85 % max.
Measurement Modes		Standard drying mode (Automatic ending/timed ending) Rapid drying mode (Automatic ending/timed ending) Slow drying mode (Automatic ending/timed ending) Step (3-stage) drying mode (Automatic ending/timed ending)
Time Settings		1 to 240 min, or continuous (up to 12 hours)
External Output		USB Data I/O printer (EP-100/EP-110) output RS-232C (D-sub 9P)
Storage of Measurement Conditions		10 sets
Data Memory		100 items
Standard Accessories		Sample pans (3 aluminum pans), pan holder, windbreak, board, aluminum sheets (50), pan handler, power cable, spare fuses (2), protective display cover, hexagonal wrench

SHIMADZU MOC63U – Datasheet
