Description

Alinco DJ-A41 Handy Talky UHF

Karya Mandiri Techindo has a wide range of Alinco products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..

Alinco DJ-A41 is a genuine Japanese HT which is designed according to customer satisfaction and operates for years under normal use. Before operating, please read the manual that has been provided from the first page to the last, to learn about all the features offered. If you only read one section, maybe you won’t understand the full explanation of its features. There are many radio stations operating on the frequency ranges covered by this radio. Be careful not to interfere with transmissions in the vicinity of the radio station.

Features Alinco DJ-A41 Handy Talky UHF

Selection Output power selectable 5W / 2W / 0.5W
128 PC programmable Channels (16ch x 8 groups)
Voice Compander (reduces Noise & improves audio clarity)
Scramble Inversion (Analog Encryption)
Sub-tone (CTCSS/DCS) Encode/Decode and DTMF
VOX is installed

Specifications Alinco DJ-A41 Handy Talky UHF

General
Frequency coverage			400-470MHz
Mode			F3E(16K0F3E / 11K0F3E )
Programmable channels			128 channels
Frequency stability			±2.5ppm
Power supply requirement			7.4V DC±20% (negative ground)
Current drain (Approx.)			1400mA TX / 300mA receive at Max audio output / 70 mA squelched
Usable temperature range			– 20— +55°C(-4—131 °F)
Dimensions (Projections not included/approx.)			59.0Wx98.0Hx35.0D mm or 2.32Wx3.86Hx1.38D inches
Antenna length			145mm
Weight			approx.227g or 8.01oz inclusive of battery pack and antenna
Transmitter
Output power			Approx. 5 / 2 / 0.5W
Modulation system			Variable reactance FM
Spurious emissions			Less than —36dBm
Max. frequency deviation			±5kHz / ±2.5kHz
Receiver
Receive system			Double conversion superheterodyne
Intermediate frequencies			38.85MHz
Sensitivity(12dB SINAD Wide/Narrow)			– 12dBM or better(0.25pV/0.35pV) or better
Selectivity			– 6dB : Wide 12kHz /Narrow 10kHz or more – 60dB : Wide 30kHz / Narrow 24kHz or less
Audio output power			1000n1W(10% distortion)

Include:

Dekstop charger
Belt clip
Battery pack
Antenna
Manual book

Video

Alinco DJ-A41 – Datasheet
