Product Description

Extech CG104 Coating Thickness Tester

The CG104 is a pocket-sized coating thickness tester which offers quick one-handed operation and non-destructive measurements of the thickness of ferrous and non-ferrous substrates. Its unique reversible display allows you to take readings in challenging angles of area being measured, plus it has an easy-to use menu system and backlit display feature. Built-in memory stores/recalls up to 255 readings. Complete with two AAA batteries, calibration standards (one ferrous plate, one non-ferrous plate and one standard coating plate film), wrist strap and soft case.

Features Extech CG104 Coating Thickness Tester

Dual Technology provides automatic recognition of ferrous (iron and steel) and non-ferrous (copper, aluminum, zinc, bronze, brass, etc) substrates
Magnetic induction for ferrous substrates
Eddy current measurement for non-ferrous substrates
180° reversible LCD display with LED backlight
Store/recall up to 255 measurements
Audible high/low limit alarms
Substrate Zeroing and two-point calibration function
Record/Recall Min/Max/Average readings
Auto-Hold freezes the reading on the display
Auto power off and low battery indicator
Complete with two AAA batteries, calibration standards (one ferrous plate, one non-ferrous plate, and one standard coating plate film), wrist strap, and soft case

Specifications Extech CG104 Coating Thickness Tester

Specifications	Ferrous	Non-Ferrous
Working Principle	Magnetic Induction	Eddy Current
Measuring Range	0 to 2000μm (0 to 80.0mils)	0 to 1000μm (0 to 40.0mils)
Resolution	1μm (0.1mils)	1μm (0.1mils)
Basic Accuracy	±4 digits (0 to 7.8mils); ±10 digits (o to 199µm)	±4 digits (0 to 7.8mils); ±10digits (0 to 199µm);
	±3% (7.9 to 39.0mils); ±3% (200µm to 1000µm)	±3% (7.9 to 39.0mils); ±3% (200µm to 1000µm);
	±5% (39.1 to 80.0mils); ±5% (1001µm to 2000µm)
Dimensions/ Weight	4.1×2.2×1.1” (105x55x27mm)/ 2.82oz (80g)
