Icom IC-F6220D

The RIG Icom IC-F6220D radio provides NXDN™ CAI-based IDAS digital mode operation. It is compatible with conventional multi-site IDAS and multi-site IDAS and one trunking site.

Product Description

Icom IC-F6220D

The RIG Icom IC-F6220D radio provides NXDN™ CAI-based IDAS digital mode operation. It is compatible with conventional multi-site IDAS and multi-site IDAS and one trunking site.

Features Icom IC-F6220D

  • IDAS™ Digital Mode Operation

The IC-F5220D series provides NXDN™ CAI-based IDAS digital mode operation. It is compatible with IDAS multi-site conventional and IDAS multi-site and single-site trunking.

  • 4W Front Mounted Speaker

4 watts* front facing speaker delivers clear and loud audio throughout a vehicle’s cabin. In addition, the digital modulation provides distinct clarity even at the fringes of the communication range.

* Typical with internal speaker

  • Channel Announcement

When you change the operating channel, the radio announces the channel number. Convenient for making radio adjustments without having to look at the radio.

  • Roaming Scan

In the multi-site trunking mode, if the signal condition worsens as the radio user moves, the roaming scan automatically finds a new site to retain the communication link and quality.

  • Built Military Rugged

The tough aluminum die-cast chassis and polycarbonate front panel have been tested to the MIL-STD-810 environmental tests.

  • Optional Accessory Cable

An external GPS receiver, PC or other equipment can be connected with the optional OPC-2078 (D-sub 25-pin) or OPC-1939 (D-sub 15-pin). The ACC connector provides an ignition switch, external PTT, serial input/output, horn honk, channel control and public address functions, according to the programming.

* No digital modulation “IN” using accessory cables.

IDAS™ Digital Mode Features

  • Up to 500 individual and up to 500 group ID aliases (Each for single-site/multi-site/conventional)
  • PTT ID and ANI
  • Call alert
  • Status
  • SDM (Short Data Message)
  • Radio check (RX)
  • Stun/kill/revive (RX)
  • RAN (Radio Access Number)
  • Remote monitor (RX)
  • Emergency
  • Digital voice scrambler
  • ATB (All Trunks Busy) ring back
  • GPS data (PC and software required to show received position data)

* TX: Transmit, RX: Receive

Other Features

  • CTCSS/DTCS encoder/decoder*
  • 128 channels with 8 zones
  • Microphone hanger action programmable
  • Power-on password function
  • Talk around function
  • Voting scan
  • Nuisance delete function
  • Forced narrow function*
  • Time-out-timer, lock-out penalty

Specifications Icom IC-F6220D

General

IC-F5220D

IC-F6220D

Frequency coverage 136–174MHz 350–400MHz
400–470MHz
450–512MHz
450–520MHz
Number of channels 128 channels/8 zones
Channel spacing 25*/15/12.5/6.25 kHz
Type of emission 16K0F3E*/11K0F3E/8K50F3E/4K00F1E/F1D
Current drain
(approx.)
Tx (High) 10A (50W) 11A (45W)
Rx (Max./Standby) 1.2A/300mA 1.2A/300mA
Dimensions (W×H×D)
(Projections not included)
150×40×167.5 mm; 5.91×1.57×6.59 in
Weight (approx.) 1.1kg; 2.4lb
Transmitter

IC-F5220D

IC-F6220D

Output power (at 13.6V DC) 50W, 25W, 5W
(Hi, L2, L1)
45W, 25W, 4.5W
(Hi, L2, L1)
Spurious emissions 87dB typ. 85dB typ.
Frequency stability ±1.0ppm
Audio harmonic distortion 3% typ.
(AF 1kHz 40% deviation)
FM Hum and Noise 50/45dB typ. (W/N) 46/40dB typ. (W/N)
FSK error 2% typ.
Receiver

IC-F5220D

IC-F6220D

Sensitivity 0.25μV typ. (Analog 12dB SINAD)
0.18μV typ. (Digital 5% BER)
Adjacent channel selectivity 80/70/65dB typ. (W/N/D) 75/66/60dB typ. (W/N/D)
Spurious response rejection 80dB typ.
Intermodulation rejection 75/75/70dB typ. (W/N/D)
AF output power
(at 5% distortion, 4Ω load)
4W typ.

*    25kHz bandwidth is no longer available for FCC Part 90 licensees for USA versions. Ask your dealer if you need 25kHz bandwidth.





Icom IC-F6220D – Manual


Produk asli Kami distributor langsung Icom . Harga murah dan berkualitas bergaransi tentunya. dapat di kirim ke seluruh wilayah indonesia.

Dalam pengiriman produk yang pelanggan beli, sebelumnya sudah kami cek untuk memastikan produk dalam keadaan baik dan siap kirim.




Additional Information

Brand

ICOM

Model

IC-F6220D

Made In

Japan

Weight

2kg
