Lutron MVB-385SD Vibration Data Recorder

Category Brand

Lutron MVB-385SD Vibration Data Recorder

  • Frequency range 10 Hz – 1kHz, sensitivity relative meet IOS 2954.
  • Profressional vibration meter supply with vibration sensor & magnetic base, full set.
  • Metric & Imperial display unit.
  • Acceleration, Velocity measurement.
  • RMS, Max hold , Peak value measurement.
  • Max. Hold reset button, Zero button.
  • Wide frequency range.
  • Data hold button to freeze the desired reading.
  • Memory function to record maximum and minimum reading with recall.
  • Separate vibration probe with magnetic base, easy operation.

Product Description

Lutron MVB-385SD Vibration Data Recorder

Innovation that is easy to use With real-time data recording via SD Card Built-in Clock and Calendar Recording intervals can be set from 5 to 3600 seconds, eliminating the need for a PC to program settings. Just save the data and insert the SD card into the PC, you can load the measurement data with date and time data (year, month, date, hour, minute, second) through Excel and can convert the data into the format of graphs or images by yourself

Features Lutron MVB-385SD Vibration Data Recorder

  • Applications for industrial vibration monitoring : All industrial machinery vibrates. The level of vibration is a useful guide to machine condition. Poor balance, misalignment & looseness of the structure will cause the vibration level increase, it is a sure sign that the maintenance is needed.
  • Frequency range 10 Hz – 1kHz, sensitivity relative meet IOS 2954.
  • Profressional vibration meter supply with vibration sensor & magnetic base, full set.
  • Metric & Imperial display unit.
  • Acceleration, Velocity measurement.
  • RMS, Max hold , Peak value measurement.
  • Max. Hold reset button, Zero button.
  • Wide frequency range.
  • Data hold button to freeze the desired reading.
  • Memory function to record maximum and minimum reading with recall.
  • Separate vibration probe with magnetic base, easy operation.
  • Real time SD memory card Datalogger, it Built-in Clock And Calenda, real time data recorder, sampling time set From 5 second to 3600 seconds.
  • Innovation and easy operation, computer is not need to setup extra software, after execute datalogger, just take away the SD card from the meter and plug in the SD card into the computer, it can down load the all the measured value with the time information (year/month/date/hour/minute/second) to the Excel directly, then user can make the further data or graphic analysis by themselves.
  • Sd card capacity : 1GB ~ 16 GB
  • LCD with green light backlight, easy reading.
  • Can default auto power off or manual power off.
  • Data hold, record max. and min. reading.
  • Microcomputer circuit, high accuracy.
  • Power by UM4/AAA( 1.5V ) x 6 batteries or DC 9V adapter.
  • RS232/USB PC COMPUTER interface.

Specifications Lutron MVB-385SD Vibration Data Recorder

  • Circuit: Custom one-chip of microprocessor LSI circuit.
  • Display: LCD size : 60 mm x 50 mm
  • Measurement: Acceleration, Velocity
  • Memory Card: SD memory card. 1 GB to 16 GB.
  • Datalogger Sampling Time: 5/10/30/60/120/300/600/1800/3600 seconds
  • Data error no.: ≦0.1 % no. of total saved data typically.
  • Update Time of Display: Approx. 1 second if measuring data is changed.
  • Advanced setting:
    * Set clock time ( Year/Month/Date, Hour/Minute/Second )
    * Set sampling time
    * Set Auto Power OFF
    * Set beeper sound ON/OFF
    * Set SD card Decimal character
    * SD memory card Format
    * Set UNIT
  • Data Output: RS 232/USB PC computer interface.
  • Operating Temperature: 0 to 50 ℃.
  • Operating Humidity: Less than 85% R.H.
  • Power Supply @Meter & probe: DC 9V adapter input. ( AC/DC power adapter is included ).
  • Power Supply @Clock backup probattery: Alkaline or heavy duty DC 1.5 V battery ( UM4, AAA ) x 6 PCs, or equivalent.
  • Weight: 199 g/0.44 LB.
  • Dimension: 132 x 80 x 32 mm ( 5.2 x 3.1 x 1.3 inch )

Accessories included:

  • Instruction manual……………….. 1 PC.
  • Vibration sensor ( VB-81A )…………………………………… 1 PC.
  • Magnetic base for VB sensor…………………..1 PC.
  • Plug for the 4-20 mA output, SKT-AS385……1 PC.

Optional Accessories:

  • SD Card
  • USB cable, USB-01.
  • RS232 cable, UPCB-02.
  • Data Acquisition software, SW-U801-WIN.
  • Excel Data Acquisition software, SW-E802.
  • AC-AP9VA (AC to DC 9V adapter)



Lutron MVB-385SD – Datasheet


Produk asli Kami distributor langsung LUTRON. Harga murah dan berkualitas bergaransi tentunya. dapat di kirim ke seluruh wilayah indonesia.

Dalam pengiriman produk yang pelanggan beli, sebelumnya sudah kami cek untuk memastikan produk dalam keadaan baik dan siap kirim.




Additional Information

Brand

Lutron

Model

MVB-385SD

Made In

Taiwan

Weight

1 kg

Accessories Included

Instruction manual
Vibration sensor ( VB-81A )
Magnetic base for VB sensor
Plug for the 4-20 mA output, SKT-AS385
