MITECH CJX-A Magnetic Flaw Detector

Meteran Cacat Bahan MITECH CJX-A adalah detektor yang diperlukan untuk melakukan pengujian cacat, kontrol kualitas, inspeksi keselamatan, evaluasi kehidupan di bidang bensin, bahan kimia, metalurgi, pembuatan kapal, penerbangan, kereta api, dll.

Product Description

MITECH CJX-A Magnetic Flaw Detector

The MITECH CJX-A Material Defect Meter is a necessary detector to carry out defect testing, quality control, safety inspection, life evaluation in the fields of gasoline, chemicals, metallurgy, shipbuilding, aviation, railway etc.

The MITECH CJX-A Material Defect Meter is a multifunctional magnetic flaw detector designed to take advantage of similar products at home and abroad. This device has a small size and light weight. Operating this device is also easy, multifunctional in one unit. The detector can equip A, D, O three kinds of probes to realize the functions of magnetic clamp detection, electromagnetic yoke detection, ring detection.

The MITECH CJX-A Meter is a necessary detector to carry out defect testing, quality control, safety inspection, life evaluation in the fields of gasoline, chemical, metallurgy, shipbuilding, aviation, railway etc. Can test flaws between 0.5~3mm below the workpiece surface, for air holes the detection depth can be up to 5mm. The magnetic participle can directly indicate defection and detect 0.1μm width.

MITECH CJX-A multifunctional magnetic flaw detector is the self-designed multifunctional magnetic flaw detector absorbed the advantages of similar products at home and abroad. With small size, light weight, easy operation, multifunction in one unit. The detector can equip A, D, O three types of probes to realize the functions of magnetic clamp detection, electromagnetic yoke detection, ring detection. It is the necessary detector to do flaw testing, quality control, safety check, life evaluation in the fields of petrol, chemicals, metallurgy, shipbuilding, aviation, railway etc..

Function & application
It is widely used in the industry of aircraft manufacturing, boiler and pressure vessel, electric, oil field, shipbuilding, combustion engine parts, mine, machinery, standard parts, oil pump, vehicle parts, bridging, chemical, railway, large mechanical components, steel structure etc.

Working Principle
Magnetize, put the workpiece into high-intensity magnetic field, connect electric to make it magnetized, if there are flaws (crack,slag) in or near the surface, there will be a leakage around the flaws. Put good quality magnetic powder(usually the magnetic iron oxide powder)on the object, magnetic powder will gather together near the leaked magnetic field, piled up to form visible traces of magnetic powder

Working Conditions

  • Power: AC 220v
  • Avoid strong vibration, place in dry area.
  • Make sure the connection condition is well, release the key when the probe leaving the workpiece. use oi to lubricate the turning joint.

Features MITECH CJX-A Magnetic Flaw Detector :

  • Indicate the shape, position, size, degree of deflection and confirm the nature of the defection, according to the effect of the magnetic field.
  • Adopt new power mode, improve detection accuracy.
  • Adjustable magnetic yoke makes the detector more practical.
  • Accessory lights can be used in dark situations.
  • Four types of probes, improve detection accuracy.
  • Different magnetic methods can test all parts of the workpiece.
  • Humanized design, magnetizing switch is easy to touch.
  • Fast detection speed and low cost.
  • Can test flaws between 0.5~3mm below the workpiece surface, for air holes the detection depth can be up to 5mm.
  • The magnetic participle can directly indicate defection and detect 0.1μm width.

Instrument Maintenance :

  • Try to avoid unplugging the cable when using.
  • Use soft cloth to clean the detector.
  • Avoid strong vibration, place in dry area.
  • When not using for a long time, you should charge it every three months to avoid damping the components.
  • After turning off the detector for 5s, boot again, do not boot immediately.
  • Make sure the connection condition is well, release the key when the probe leaving the workpiece. use oi to lubricate the turning joint.

Specifications MITECH CJX-A Magnetic Flaw Detector :

Complex sensitivity clearly show the artificial notch of type A 30/100 standard specimen
Lifting ≥45N(no less than 5kg)
Working conditions when continuous working, magnetizing time≤3s, clearance time≥5s
Weight about 7.0KG
Probe temperature-rise ≤60℃
Flaw detection speed ≥6m/min
Power output AC36V*2, 15A, can equip A, D, O four probes
Power input AC220V, ±10%, 50HZ,5A


Produk asli Kami distributor langsung Mitech . Harga murah dan berkualitas bergaransi tentunya. dapat di kirim ke seluruh wilaya indonesia.

Dalam pengiriman produk yang pelanggan beli, sebelumnya sudah kami cek untuk memastikan produk dalam keadaan baik dan siap kirim.
