Product Description
Noyafa NF-521 Thermal Imaging Camera
Karya Mandiri Techindo has a wide range of Noyafa products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
Features Noyafa NF-521 Thermal Imaging Camera
- 【Temperature testing】The measuring range is -10°C ~ 400°C.Capturing an astonishing level of detail through high thermal sensitivity,isolating the smallest temperature anomalies.
- 【Resolution】32×32 pixel resolution, 33° Field of View.Capture a clear, accurate image focused throughout the field of view.
- 【IR thermal imaging camera technics】Use 2 megapixel white lens and 2.4 TFT LCD screen to visualize targets more flexibly.
- 【Integrated visual display】Combine infrared and visible images for simpler analysis and edit and optimize images.
- 【Certification】Passes RoHS, FCC and CE compliance testing, and Noyafa is certified to the ISO 9001 standard.
- 【100% Affordable】A lot cheaper than Fluke, Milwaukee, Snap-on, and Klein thermal imagers.
Specifications Noyafa NF-521 Thermal Imaging Camera
- Is_customized: Yes
- Brand Name: Noyafa
- Model Number: NF-521
- Place of Origin: Shenzhen.China
- Temperature measurement range: -10~400℃
- Color: Red+Grey
- Power: 3.7V Lithium battery
- Warranty: 1Year
Technical Index
| Infrared temperature measurement | |
| Temperature measurement range | -10~400℃ |
| Basic accuracy | ±2% or ±2.0℃ |
| Emissivity | adjustable 0.1~0.99 |
| Measuring resolution | 0.1℃ |
| Response time | 150ms |
| Spectral band | 8~14um |
| Thermal imaging technique | |
| Thermal imaging resolution | 32*32（1024 pixels） |
| Electronic shutter | No |
| Visible light camera | 2 megapixels |
| Display resolution | Thermal imaging, thermal mixing, digital camera |
| Color palettes | Ironbow,iridescence ,Grayscale |
| Infrared spectral bandwidth | 8~14μm |
| FOV | 33° horizontal |
| IFOV | 18 mrad |
| Thermal imaging sensitivity | 150mk |
| Frame rate | ≤9Hz |
| Image format | BMP |
| General parameters | |
| Monitor | 2.4 & rdquo; TFT LCD |
| Display resolution | 320*240 pixels |
| Battery | 3.7V/2600mAh |
| Automatic shutdown function | Yes |
| Certification | CE |
| SD card | 8GB TF card |
| Working temperature | -10℃~45℃ |
| Drop proof | 2m |
| Standard accessories | manual, USB cable, 8GB micro TF card |
Noyafa NF-521 – Manual
Produk asli Kami distributor langsung Noyafa . Harga murah dan berkualitas bergaransi tentunya. dapat di kirim ke seluruh wilayah indonesia.
Dalam pengiriman produk yang pelanggan beli, sebelumnya sudah kami cek untuk memastikan produk dalam keadaan baik dan siap kirim.
