TIME 7230 Vibration Meter Portable
Karya Mandiri Techindo has a wide range of TIME products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
TIME7230 is a powerful digital vibration meter. It is suited for measuring vibration of motor, electric fan, pump, compressor and other rotating machine tools.
Features TIME 7230 Vibration Meter Portable
- Two display modes: digital value mode and spectrum mode
- Large memory function: 100 x 100 measured results (100 testing points, 100 data can be stored in each testing points), 100 spectrograms (each testing point can store one spectrogram)
- Spectrogram can display in real time
- Histogram can be made according to the preset alarm line
- Upper /lower limits pre-setting and sound alarm if test results out of limitation, which leads to spectrum analysis mode automatically
- Connected to PC with advanced software for more analysis needs
- Integrated with printer to print out the testing result
- 300 x 200 matrix LCD display with backlight
- Two probes for option: low and high sensitivity probes
Specifications TIME 7230 Vibration Meter Portable
Measuring range | Low sensitivity probe | |
Acceleration | 0.1m/s2-392m/s2 (peak) | |
Velocity | 0.01cm/s-80cm/s (RMS) | |
Displacement | 0.001mm-18.1mm (peak-peak) | |
High sensitivity probe | ||
Acceleration | 0.1m/s2-20m/s2 (peak) | |
Velocity | 0.01cm/s-4cm/s (RMS) | |
Displacement | 0.001mm-0.8mm (peak-peak) | |
Frequency range | Low sensitivity probe: | |
Acceleration | 10Hz-200Hz,10Hz-500Hz, | |
10Hz-1KHz,10Hz-10KHz | ||
Velocity | 10Hz-200Hz, 10Hz-500Hz,10Hz-1KHz | |
Displacement | 10Hz-200Hz,10Hz-500Hz | |
High sensitivity probe | ||
Acceleration | 10Hz-200Hz,10Hz-500Hz, | |
10Hz-1KHz,10Hz-10KHz | ||
Velocity | 10Hz-200Hz, 10Hz-500Hz,10Hz-1KHz | |
Displacement | 10Hz-200Hz,10Hz-500Hz | |
Accuracy | ±5% | |
Power | Li battery (continuous working 20 hours without backlight) | |
Temperature | 0~40℃ | |
Humidity | ≤80%RH | |
Dimension (mm) | 171×78.5×28 | |
Weight (g) | 230 | |
| Standard Delivery | Optional Accessory | |
| Main unit | 1 | Needle groupware |
| Protection pocket | 1 | |
| Low sensitivity probe | 1 | |
| High sensitivity probe | 1 | |
| Power adapter | 1 | |
| Magnetic base | 1 | |
| TIME certificate | 1 | |
| Warranty card | 1 | |
| Instruction manual | 1 |
