ETCR2000A+ Clamp Earth Resistance Tester
Karya Mandiri Techindo has a wide range of ETCR products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
Quality Clamp Resistance Tester from ETCR Electronics
With a clamp size of 65mm X 32mm
Product Main Function
- Measurement of earth resistance,loop resistance
- Measure Range: 0.010Ω~200Ω
- Data Storage: 99 sets
- Alarm Threshold Setting: 1-199Ω
- Alarm Function: audible and visible alarm
- CT Size: 65mmX32mm
Specifications ETCR2000A+ Clamp Earth Resistance Tester
| Power Supply | 4 PCS of LR6 lkaline batteries | ||
| Clamp Size | 65mm×32mm | ||
| LCD Size | 4 Digits LCD display, Screen : 47mm×28.5mm | ||
| Range | 0.010Ω~200Ω | ||
| Resolution | 0.001Ω | ||
| Accuracy | ±1%±0.01Ω | ||
| Data Storage | 99 sets | ||
| Data Upload Function | RS232 Interface (Optional) | ||
| Auto Power-off | Automatically power off after 5 minutes without any operate | ||
| Power Consumption | ≤50mA, continuously working for 30 hours | ||
| Working Environment | -20oC~55oC ; 20%rh~80%rh | ||
| Store Environment | -20oC~60oC ; below 90%rh | ||
| Alarm threshold setting range Resistance | 1~199Ω | ||
| Audible and VisibleAlarm | “Beep-beep-beep” alarm sound, alarm symbol flashing, pressALkey to turn on/off and setting | ||
| Interference Signal Recognition | “Beep-beep-beep” indicator,NOISEsymbol blinking | ||
| Protection Level | Double insulation | ||
| Structural Feature | Clamp CT | ||
| Shift | Automatic shift | ||
| External Magnetic Field | <40A/m | ||
| External Electrical Field | <1V/m | ||
| Single Measurement Time | 0.5 second | ||
| Resistance Measurement Frequency | >1KHz | ||
| Measured Current Frequency | 50/60Hz Automatic | ||
| Low Battery Voltage Indicator | When the battery voltage is lower than 5.3V, the low battery voltage symbol is displayed | ||
| Storage Full Indication | Storage data full of 99 sets,flashed display “MEM” symbol | ||
| Over Range Indication | Exceed range indication “OL Ω ”, “L0.01” or “OL A” | ||
| Tester Weight | 1160g | ||
| Tester Dimension | 285mm×85mm×56mm |
ETCR2000A+ – Datasheet
