Sanwa DCM400 Clamp Meter

Karya Mandiri Techindo has a wide range of Sanwa products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..

Features Sanwa DCM400 Clamp Meter :

4000 count / 42 segment analog bar graph
Frequency measurement by clamping and using 　test lead
Data hold
Continuity check buzzer
Auto power off (30min.)
Low battery power indication
Sampling rate : 2 times / sec. for numeral display
AC frequency
bandwidth : 50〜60Hz (ACA : 1.9%±5), 60〜500Hz (ACA : 2.5%±5), 50〜500Hz (ACV)

Specifications Sanwa DCM400 Clamp Meter :

Function	Measuring range	Best accuracy	Resistance
ACA	40/400A	±(1.9%+5)	0.01A
ACV	400/600V	±(1.5%+5)	0.1V
DCV	400/600V	±(1%+2)	0.1V
Resistance	400Ω	±(1%+2)	0.1Ω
Frequency (A)	20～4k/10kHz	±(0.1%+1)	1Hz
Frequency (V)	4k/40k/400k/1MHz	±(0.1%+1)	0.001kHz
Continuity	Buzzer sounds at less than approx. 40Ω Open voltage: approx. 1.5V

Sampling rate	2 times/sec., 20 times/sec. for bar graph
Bandwidth	ACA 50/60Hz: ±(1.9%+5） 60-500Hz: ±(2.5%+5） ACV 50-500Hz: ±(1.5%+5)
Display	4000
Clamp diameter/Conductor size	Φ25mm/10×34mm
Battery	R03×2
Battery life	Approx. 150 hrs. (Zinc-carbon battery)
Size/Mass	H193×W50×D28mm/Approx. 230g
Safety standards	IEC61010 CAT.Ⅲ300V CAT.Ⅱ600V

Standard Accessories

Test lead: TL-23a
Carrying case: C-DCM400

Optional Accessories

Clip adapter : CL-13a, CL-14,CL-15a, CL-DG3a, TL-9IC
Test lead : TL-21M, TLF-120

Sanwa DCM400 – Datasheet
