SHIMADZU AP324W Analytical Balance
Karya Mandiri Techindo has a wide range of SHIMADZU products – search by type, or model, or filter by brand to find the one you are after. If you still can’t find it contact us..
The AP Series of analytical balances encompasses the APW, APW-D, APX, and APY models, and incorporate innovative features and accessories, as well as Shimadzu’s most advanced one-piece UniBloc weighing sensor.
Features SHIMADZU AP324W Analytical Balance
Fast Weighing Response
Shimadzu’s advanced one-piece UniBloc AP weighing sensor reduces the weighing response time by approximately 20% compared with the previous model, significantly improving weighing efficiency.
Optional Built-In High-Performance Ionizer
The STABLO AP ionizer is mountable in APW, APW-D, and APX models, and eliminates the influence of static electricity, making powders and objects easier to handle and weigh.
Ensure Data Reliability with LabSolutions Balance Software
Integration with LabSolutions Balance enables automatic saving of weighing data in compliance with electronic record (ER) and electronic signature (ES) regulations. In addition, LabSolutions is compatible with a host of Shimadzu’s analytical instruments, including chromatography, mass spectrometry, molecular spectroscopy, and elemental analysis, allowing weighing data to be combined with data from these instruments in reports.
Buffer Solution and Sample Recipe Functions
For the new APW and APW-D models, recipes for 13 commonly used buffer solutions are included as standard, and new buffer solution recipes are easily registered, with preparation instructions and guidance shown on the display. Sample recipes can also be registered, increasing the efficiency of repetitive weighing tasks.
Time-Saving Accessories
A multi-stand is included with 0.01 mg models, supporting easier weighing with weighing paper, into micro tubes, and of long rod-shaped samples. A numeric keypad makes entering numeric values quicker, and by scanning a barcode with the barcode reader, sample IDs, as well as user IDs and passwords, are inputted.
Specifications SHIMADZU AP324W Analytical Balance
| Model | AP225W-AD | AP135W-AD | AP225WD-AD | AP125WD-AD | AP324W-AD | AP224W-AD | |
|---|---|---|---|---|---|---|---|
| Capacity | 220g | 135g | 220g / 102g | 120g / 52g | 320g | 220g | |
| Minimum Display | 0.01mg | 0.1mg / 0.01mg | 0.1mg | ||||
| Calibration Weight | Built-in (*1) | ||||||
| External Calibration Weight Range for Span Calibration (Recommended weight value) | 95 to 220.00090g (200g) | 45 to 135.00090g (100g) | 95 to 220.00090g (200g) | 45 to 120.00090g (100g) | 95 to 320.0090g (300g) | 95 to 220.0090g (200g) | |
| Repeatability (at weighing capacity) (*2) | 0.015mg (up to 20g) 0.03mg (up to 100g) 0.05mg (up to 200g) | 0.05mg | 0.1mg / 0.05mg | 0.1mg / 0.02mg | 0.15mg | 0.1mg | |
| Repeatability (for low loads) (*2, *3) | 0.01mg (for 5g load) | 0.1mg (for 20g load) | 0.1mg (for 10g load) | ||||
| Minimum Weight (*2, *3) | 20mg (*2) | 200mg | |||||
| Linearity (*2) | ±0.1mg | ±0.2mg / ±0.1mg | ±0.2mg / ±0.05mg | ±0.3mg | ±0.2mg | ||
| Response Time for Trace Measurements (*4, *5) | 2 sec. | ||||||
| Response Time (*5) | 8 sec. | 2 sec. / 8 sec. | 2 sec. | ||||
| USB Host (Type A) | ○ | ||||||
| USB Device (Type B) | ○ | ||||||
| Recipe Compounding | ○ | ||||||
| HPLC Buffer Solution Preparation | ○ | ||||||
| mol Conversion Function | ○ | ||||||
| Sample (Concentration) Preparation | ○ | ||||||
| Inspection Support Function | ○ | ||||||
| Clock-CAL | ○ | ||||||
| Automatic Doors | ○ | ||||||
| Touchless Sensors | ○ | ||||||
| Adjustable Windbreak Plate | ○ | – | |||||
| Ionizer | ○ | ||||||
| Operational Temperature / Humidity Range | 5 to 40℃ at 20 to 85% RH (*6) | ||||||
| Sensitivity Stability Against Temperature Range | ±2ppm / ℃ (10～30℃) | ||||||
| Pan Size | Approx. 91 mm dia. | ||||||
| Body Dimensions | Approx. W215 × D411 × H346 mm (power supply unit included) | Approx. W215 × D367 × H346 mm | |||||
| Weight | Approx. 9.7kg | Approx. 8.6kg | |||||
| Display | OEL display (dot matrix) | ||||||
| Rated Electric Power Supply | DC12V 1.5A | ||||||
| Power Supply Input (AC Adapter) | AC100-240V 480mA 50/60Hz (*7) | ||||||
| Input / Output Terminal | RS-232C (D-Sub 9P plug) USB host (Type A) USB device (Type B) Ionizer | ||||||
SHIMADZU AP Series – Datasheet
